DDAMPL has been involved in Hardware & Software development activities over the last few decades in verticals like Consumer, Industrial & Automotive domains. DDAMPL is a complete Design & Service house for product development & manufacturing.
PCB Design Capabilities
- Turnkey PCB Layout
- Layer stack up / Placement / Routing / Signal integrity/ Gerber Generation:
- Number of layers varying from 2 to 30
- Components Pitch of 0.5mm, 0.65mm, 0.8mm, 1mm, etc.
- Minimum trace width/separation of 3/3mils
- Experience in HDI (High Density Interconnect)-Buried and Blind Vias technology
- High speed signal routing in the range of 10 Giga bit
Hardware Testing & Certification
DDAMPL has a wide range of experience in functional testing of the design with the in-house test facilities. On Customer request, DDAMPL can get the product certification done through our external approved labs for Environment testing like temperature, humidity, vibration, and EMI /EMC, ESD etc.
Our Strengths
- Development of Digital, Analog, RF and High-Speed design
- Minimal / Zero Cuts and Straps in prototyping
- Design for Manufacturing (DFM), Design for Testability (DFT)
- Established quality process with our ecosystem partners for volume manufacturing.
